Water & Wastewater Control Panels
Lift station, booster, chemical feed, and treatment panels built to UL 508A in 316 stainless NEMA 4X — SCADA-ready, functionally tested against simulated level inputs, and shipped with as-built documentation.
UL 508A Certified Shop • U.S. Veteran-Owned • Las Vegas, NV
Panels for the plant & the field
Lift station panels
Duplex and triplex pump control with alternation, seal-fail and over-temp monitoring, high-level alarm, and elapsed-time metering.
Booster & VFD panels
Pressure-controlled pump packages with drives, line reactors, bypass contactors, and transducer or PID control.
Chemical feed & dosing
Metering pump control with flow pacing, residual analyzer inputs, leak detection, and corrosion-resistant enclosures.
Blower & aeration control
Basin aeration and digester blower panels with dissolved-oxygen trim, staging logic, and thermal protection.
RTU & SCADA cabinets
Telemetry cabinets with cellular or radio provisions, surge-protected I/O, antenna entries, and clean grounding.
Retrofits & re-panels
Drop-in backplates and new stainless cabinets that modernize aging stations with minimal downtime at changeover.
Panel specifications
Send the spec section and approved-manufacturer list — we submit shop drawings for approval before fabrication.
Request a Quote| Enclosures | 316 and 304 stainless NEMA 4X, NEMA 3R, NEMA 12; sloped tops, sun shields, pad or rack mounting |
|---|---|
| Standards | Built and labeled to UL 508A with documented SCCR; wired to NEC Article 409 practice |
| Power | 120–480 VAC, single- and three-phase, through 400 A main |
| Controls | Allen-Bradley, Siemens, and AutomationDirect PLCs and HMIs; relay logic where specified |
| Level & instruments | Floats, submersible transducers, ultrasonic, conductance probes, flow and residual analyzers |
| Motor control | VFDs, soft starts, and across-the-line starters with line reactors and output filtering |
| Protection | Surge suppression, phase monitors, intrinsically safe relays for classified wet wells |
| Telemetry | Cellular and radio RTU provisions, Modbus TCP / Ethernet I/P, alarm dialers |
| Testing | Point-to-point continuity, powered functional simulation of level and alarm inputs, hi-pot on request |
| Documentation | Submittal package, as-built drawings, panel schedule, BOM, and O&M manual |
Off our floor
Are your pump panels built and labeled to UL 508A?
Yes. Panels are built to the UL 508A standard with a documented short-circuit current rating, and we supply the panel schedule, as-built drawings, and bill of materials with the shipment so the installing contractor and the inspector have what they need at startup.
Can you provide intrinsically safe circuits for wet wells?
Yes. Float, transducer, and conductance inputs from a classified wet well are landed through intrinsically safe relays or barriers, kept in segregated wireways, and terminated on dedicated blue terminal blocks so field wiring stays clearly separated from power.
Can you build to a municipal or plant standard?
Yes. Send the specification section and any approved-manufacturer list. We build to the named PLC, drive, and component brands, follow the required wire colors, numbering, and labeling conventions, and submit shop drawings for approval before fabrication starts.
Can you retrofit an existing panel or supply the enclosure only?
Both. We re-panel existing lift stations onto a new backplate for a rapid changeover, and we also supply stainless NEMA 4X enclosures with cutouts, subpanels, and glands for integrators who do their own wiring.
Send us your spec section
Pump data, level strategy, and the approved-manufacturer list are enough to quote. Response within one business day.
